HB-150W hydraulic busbar machine

HB-150W hydraulic busbar machine for brass busbar bending cutting and hole punching.

Portable three in one hydraulic busbar processing machine on a movable worktable for copper busbar works.

Complete hydraulic busbar processing machine include hydraulic bender, hydraulic cutter, hydraulic hole puncher.

HB-150W:for working max up to 150mm of width, 10mm of thickness, and 95mm of punching throat.

HB-200W:for working max up to 200mm of width, 12mm of thickness, and 110mm of punching throat.

Punching hole sizes 10.5mm, 13.8mm, 17mm, 20.5mm.

Other sizes 5mm, 5.5mm, 6mm, 6.5mm, ..., 22mm are for selected.

Three hydraulic working units to be drived by an electric hydraulic pump M4107, works for AC power 110V, 220V, 380V can be select.

Machines can be color yellow, blue, red, black.

Complete busbar machine weight around at 170kg, packed in ply-wooden case, suitable for sea shipping.

For more information, please feel free to contact Jeteco Tools.
